CHAPTER 8 — STEERING / SUSPENSION
PART DESCRIPTION
TORQUE
SPECIFICATION
Steering Gear Box Pinch
Bolt
48 lb-ft (65 Nm)
Steering Wheel Tilt
Assembly Fasteners
40 lb-ft (54 Nm)
Steering Wheel Nut 65 lb-ft (88 Nm)
EPS Unit Mount Bolts 30 lb-ft (41 Nm)
EPS Unit Frame Bolts 14 lb-ft (19 Nm)
EPS Unit Pinch Bolts 15 lb-ft (20 Nm)
Tie Rod Jam Nut
13 lb-ft (18 Nm)
Shock Mounting Bolts 40 lb-ft (54 Nm)
Lower A-Arm Fasteners
40 lb-ft (54 Nm)
Ball Joint Pinch Bolts
42 lb-ft (57 Nm)
Wheel Nuts (Steel
Wheels)
60 lb-ft (81 Nm)
Wheel Nuts (Cast
Aluminum Wheels)
120 lb-ft (163 Nm)
Upper A-Arm Fasteners
40 lb-ft (54 Nm)
Front Caliper Mounting
Bolts
30 lb-ft (41 Nm)
Stabilizer Bar Fasteners 17 lb-ft (23 Nm)
CHAPTER 9 — BRAKE SYSTEM
PART DESCRIPTION
TORQUE
SPECIFICATION
Caliper Bleed Screws 47 lb-in (5.3 Nm)
Brake Line Banjo Bolts
15 lb-ft (20 Nm)
Master Cylinder Mounting
Bolts
23 lb-ft (31 Nm)
Brake Pedal Mount
Bracket Nuts
18 lb-ft (24 Nm)
Front Caliper Mounting
Bolts
30 lb-ft (41 Nm)
Wheel Nuts (Steel
Wheels)
60 lb-ft (81 Nm)
Wheel Nuts (Cast
Aluminum Wheels)
120 lb-ft (163 Nm)
CHAPTER 9 — BRAKE SYSTEM
PART DESCRIPTION
TORQUE
SPECIFICATION
Front Brake Disc
Mounting Bolts
18 lb-ft (24 Nm)
Front Wheel Hub Castle
Nuts
80 lb-ft (108 Nm)
Rear Caliper Mounting
Bolts
46 lb-ft (62 Nm)
Rear Brake Disc
Mounting Bolts
28 lb-ft (38 Nm)
Rear Wheel Hub Castle
Nuts
110 lb-ft (149 Nm)
CHAPTER 10 — BODY / FRAME
PART DESCRIPTION
TORQUE
SPECIFICATION
Half Door Hinge to Frame
Fasteners
8 lb-ft (10 Nm)
Half Door Hinge
Fasteners
14 lb-ft (19 Nm)
Full Door Hinge
Fasteners
17 lb-ft (23 Nm)
Heater Mounting
Fasteners
6–8 lb-ft (8–10 Nm)
Roof Fasteners 12–15 lb-in (1.35–1.7
Nm)
Windshield Mount
Fasteners
15 lb-ft (20 Nm)
Tip Out Windshield Mount
Fasteners
20 lb-ft (27 Nm)
Wiper Motor Shaft
Fastener
15 lb-ft (20 Nm)
Wiper Arm Fastener
10 lb-ft (14 Nm)
Cargo Box Hinge
Fasteners
14 lb-ft (19 Nm)
Front Brushguard
Fasteners
30 lb-ft (41 Nm)
Rear Brushguard
Fasteners
12 lb-ft (16 Nm)
Nerf Bar Fasteners 12–15 lb-ft (16–20 Nm)
Winch Fasteners
25 lb-ft (34 Nm)
