9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
4.37
COMPONENT CONDITION SPN FMI P-CODE
Fan Relay Driver Circuit
Driver Circuit Open / Grounded
1071
5
P1481
Driver Circuit Short to B+ 3 P1482
Driver Circuit Grounded 4 P1483
Ignition Coil Primary Driver 1
(MAG)
Driver Circuit Short to B+ 1268 3 P1353
Ignition Coil Primary Driver 2
(PTO)
Driver Circuit Short to B+ 1269 3 P1354
Fuel Pump Driver Circuit
Driver Circuit Open / Grounded
1347
5 P0230
Driver Circuit Short to B+ 3 P0232
Driver Circuit Grounded 4 P0231
Oxygen Sensor
Data erratic, intermittent or
incorrect
3056
2 P0130
Voltage above normal
3 P0132
Voltage below normal
4 P0131
ECU Output Supply Voltage 1
Voltage Too High
3597
3 P16A2
Voltage Too Low
4 P16A1
ECU Output Supply Voltage 2
Voltage Too High
3598
3 P16A9
Voltage Too Low
4 P16A8
ECU Output Supply Voltage 3
Voltage Too High
3599
3
P17AA
Voltage Too Low
4 P17AB
Misfire Detected
Cylinder Not Identified
65590 7 P0314
Cylinder 1
65591
7 P0301
Cylinder 2
65592
7 P0302
ETC Accelerator Position
Sensor Outputs 1 & 2
Correlation
Correlation Fault 65613 2 P1135
Throttle Position Sensor 2
Voltage Too High
520198
3 P0223
Voltage Too Low
4 P0222
Signal Out of Range
2 P0221
All Wheel Drive Control Circuit
(AWD)
Driver Circuit Open / Grounded
520207
5 P1836
Driver Circuit Short to B+ 3 P1835
Driver Circuit Grounded 4 P1834
Oxygen Sensor Heater
Voltage above normal
520209
3 P0032
Voltage below normal
4 P0031
Current below normal or open
circuit
5 P0030
Steering Over Current Shut
Down
Current Above Normal or
Grounded
520221 6 C1050
Steering Excessive Current
Error
Current Above Normal or
Grounded
520222 6 C1051
Steering Torque Partial Failure
Condition Exists 520223 31 C1052
Steering Torque Full Failure
Condition Exists 520224 31 C1053
EPS Inverter Temperature
Greater than 110° C (230° F)
520225
16 C1054
Greater than 120° C (248° F)
0 C1055
EPS CAN Communications
Receive Error
No RX Message for 2 Seconds
520226 2 U0100
FUEL SYSTEM
