2. Install brake line and torque the banjo bolt
e
to the
proper torque specification.
TORQUE
Brake Line Banjo Bolts:
15 lb-ft (20 Nm)
3. Install the pad adjustment screw and turn until
stationary pad contacts disc, then back off 1/2 turn.
4. Follow the “Brake Bleeding / Fluid Change”
procedure as outlined earlier in this chapter.
5. Install wheel and torque wheel nuts to specification.
TORQUE
Wheel Lug Nuts (Steel Wheels) 36 ft-lbs (49 Nm)
Wheel Lug Nuts (Aluminum Wheels) 30 ft-lbs + 90º (41
Nm + 90º)
6. Field test unit for proper braking action before putting
into service. Inspect for fluid leaks and firm brakes.
Make sure the brake is not dragging when pedal is
released. If the brake drags, re-check assembly and
installation.
NOTICE
If new brake pads are installed, brake burnishing is
recommended.
