COMMUNICATION MULTI GAUGE CONTROLLER
Table 6.16 – continued from previous page
NAME OF VARIABLE ADDRESS TYPE KIND RANGE [UNIT]
MAC address 5020 R 6*UINT8
MAC address - ProiNet 5030 R 6*UINT8
Table 6.16: Additional registers map
Value Description
VACUUM GAUGE TYPES
ACTIVE GAUGES
0 CTR90
1 TTR90
2 TTR211
3 PTR225
4 ITR90
5 ITR100
6 MKS870
7 PTR90
8 ANALOG_IN
9 MKS_937A
10 PG105
11 MG13_14
12 PKR251/360/361
13 PCR280/TPR28x
14 ATMION
15 User Deined Vacuum Gauge
16 IKR360/361
PASSIVE GAUGES
0 UHV8A
1 IE514
2 IE414
3 UHV24
4 UHV24p
5 MKS274
6 NR_F_UHV
7 G8130
8 User Deined Passive Vacuum Gauge
9 BARION basic II
Table 6.17: Vacuum gauge types
Value Description
VACUUM GAUGE POSSIBLE STATUSES
0 Status OK
1 Wait for emission
2 Emission OFF
3 Short cathode
continued on next page
Page 106 User manual rev. 03
