Table 6.20 – continued from previous page
Value Description
4 Kr
5 Xe
6 H2
7 CO
8 deine
Table 6.20: Gas types
Value Description
SETPOINTS SOURCE ASSIGNMENT OPTIONS
1 Vacuum channel 1
2 Vacuum channel 2
3 Vacuum channel 3
4 Vacuum channel 4
5 Vacuum channel 5
6 Vacuum channel 6
7 Vacuum channel 7
100 Always ON
101 Always OFF
Table 6.21: Setpoints source assignment options
Value Description
DIGITAL OUTPUTS ASSIGNMENT OPTIONS
0 Not assigned
1 Emission passive channel 1
2 Emission passive channel 2
3 Emission passive channel 3
4 Emission active channel 1
5 Emission active channel 2
6 Emission active channel 3
7 Emission active channel 4
8 Degas passive channel 1
9 Degas passive channel 2
10 Degas passive channel 3
11 Degas active channel 1
12 Degas active channel 2
13 Degas active channel 3
14 Degas active channel 4
15 Always OFF
16 Always ON
Table 6.22: Digital outputs assignment options
