Prevac MG15 - Device Speci Ication; Dimensions

MULTI GAUGE CONTROLLER INTRODUCTION
continued from previous page
PARAMETER DESCRIPTION
Resolution of converter 0.1fA
Accuracy of measurement 3fA***
Sampling frequency 10sps
Screen refreshment 10 sps
Temperature drift Automatically adjusted by internal temperature
control
GAUGE CONNECTION
Active gauge RJ45
Passive gauge UTG0187SVDEU + BNC
COMMUNICATION
Communication interfaces RS232/485, Ethernet, PROFINET*
I/O
Digital inputs 4
Digital outputs 4
Analogue outputs 4 (0-10V)
AMBIENCE
Operating temperature range +5 ºC - +40 ºC
Storage temperature range 0 ºC - +70 ºC
Relative humidity Max. 80% (to 31°C), decreased linearly down to max.
50% (at 40°C)
MECHANICAL PARAMETERS
Dimensions Width: 212.6 mm
Height: 128.4 mm
Depth: 260.3 mm
Weight 4.2 kg
Installation Rack mounted or Desktop device
(*) - optional
(**) - additional gauges can be deined, see section 3.6.1.3 or 3.6.1.5.
(***) - at lowest range (highest vacuum).
Table 1.1: Device speciication
User manual rev. 03 Page 17
