MULTI GAUGE CONTROLLER COMMUNICATION
Value Description
ANALOGUE OUTPUTS CONTROL SOURCES OPTIONS
0 Not assigned
1 Pressure of passive channel 1
2 Pressure of passive channel 2
3 Pressure of passive channel 3
4 Pressure of active channel 1
5 Pressure of active channel 2
6 Pressure of active channel 3
7 Pressure of active channel 4
Table 6.23: Analogue outputs assignment options
Value Description
ANALOGUE OUTPUTS CONTROL MODES OPTIONS
0 Mode 1 do 1
1 Logarithmic mode
2 User-deined mode
Table 6.24: Analogue outputs modes options
Value Description
ANALOGUE OUTPUTS SCALES OPTIONS
0 Linear scale
1 Logarithmic scale
Table 6.25: Analogue outputs scales options
User manual rev. 03 Page 109
