INTRODUCTION MULTI GAUGE CONTROLLER
1.5 SPECIFICATION
1.5.1 TECHNICAL DATA
PARAMETER DESCRIPTION
ELECTRICAL PARAMETERS
Power supply 100-240 VAC
Frequency 50 - 60 Hz
Current consumption 1.8A (110V)
0.85A (230V)
Maximum power consumption 200 W
Protection class I
Overvoltage category II
Power supply connection socket European connection socket IEC 60 320 C13
Fuse 3.15A (250V)
6.3A (125V)
MEASUREMENT CHANNELS
Measurement channels 4 active channels
up to 3* passive channels
Supported active gauges** CTR90, TTR91, TTR211, PTR225,
PKR251/360/361, PCR280, TPR280/281, PTR90,
ITR90, ITR100, Baratron, ANALOG IN, PG105,
ATMION, IKR360/361
Supported passive gauges** IE414, IE514, UHV-24, UHV-24p, MKS Series 274,
NUDE-UHV-8A, NR-F-UHV, G8130, BARION basic II
MEASUREMENT RANGE
Active gauges 5x10
mbar (depending on type)
Passive gauges 2x12
mbar (depending on type)
VOLTAGE MEASUREMENT SPECIFICATION
Resolution of converter 0.6𝜇V
Accuracy of measurement 2𝜇V
Sampling frequency 12 sps
CURRENT MEASUREMENT SPECIFICATION
continued on next page
Page 16 User manual rev. 03
