Prevac MG15 - Interface Selection; DIP Switches Functions

INSTALLATION MULTI GAUGE CONTROLLER
Communication interface can be selected as shown below:
5 - OFF 6 - OFF RS232
5 - OFF 6 - ON RS485
5 - ON 6 - X ProiNet
Table 2.7: Interface selection
• without ProiNet communication socket
DIP FUNCTION
1-5 Address
6 RS232/RS485
Table 2.8: DIP switches functions
To set an address use switches 1 - 5. Refer to table 2.5 for weights of switches.
Communication interface can be selected as shown below:
6 - ON RS485
6 - OFF RS232
Table 2.9: Interface selection
Page 30 User manual rev. 03
