COMMUNICATION MULTI GAUGE CONTROLLER
6.4.5.2 0x06 - WRITE WORD
Query:
Device
address
Function
code 0x06
Address of word to
be written
Value to be written CRC
1 byte 1 byte MSB LSB MSB LSB MSB LSB
Response:
Device
address
Function
code 0x06
Address of word to
be written
Value to be written CRC
1 byte 1 byte MSB LSB MSB LSB MSB LSB
Slave device is identical with query. Except when transmission error or incorrect data occur. Pos-
sible responses in case of error are described in table 6.4.6.
Example: Write word to address 0x004A.
Query:
TX: 01 06 00 4A 02 00 A9 7C
Response:
RX: 01 06 00 4A 02 00 A9 7C
6.4.5.3 0x10 - WRITE N-WORDS
It enables sequential writing of a number of parameters within one transmission.
It is necessary to deine the address of the irst parameter and number of words to be written after
this address.
Query:
Device
address
Function
code 0x10
First word
address
Number of
words to be
written
Number
of data
bytes
Data ... CRC
1 byte 1 byte MSB LSB MSB LSB 1bajt MSB
LSB
... MSB
LSB
Response:
Device
address
Function code
0x10
First word address Number of written
words
CRC
1 byte 1 byte MSB LSB MSB LSB MSB LSB
The maximum number of words to be written is 125 which corresponds to 250 bytes. The irst two
bytes are the data for the irst parameter (irst MSB in organisation). The subsequent byte pairs are
the data for the following parameters. Trying to write using function 0x10 of data blocks containing
non-conigured (empty) cells, or read only, results in communication error and discarding of the
data. All the further values in the block will also be discarded.
