Remote control commands
R&S
®
LCX Series
197User Manual 1179.2260.02 ─ 02
FUNCtion:IMPedance:SOURce <Impedance>
FUNCtion:IMPedance:SOURce? <Impedance>
Selects the output impedance for the measurement.
Parameters for setting and query:
<Impedance> LOW | R10 | HIGH | R100
LOW | R10
Sets 10 Ω output impedance.
HIGH | R100
Sets 100 Ω output impedance.
*RST: HIGH
Example: See Example "Selecting the measurement function and setting
the impedance range" on page 195.
Manual operation: See "Source Impedance" on page 76
FUNCtion:IMPedance[:TYPE] <Impedance Type>
FUNCtion:IMPedance[:TYPE]? <Impedance Type>
Selects the impedance parameter for the measurement corresponding to the measure-
ment type, see FUNCtion:MEASurement:TYPE on page 198.
Parameters for setting and query:
<Impedance Type> CPD | CPQ | CPG | CPRP | CSD | CSQ | CSRS | LPD | LPQ |
LPG | LPRP | LSD | LSQ | LSRS | RX | RPB | RDC | MTD |
NTD | ZTD | ZTR | GB | YTD | YTR
CPD | CPQ | CPG | CPRP | CSD | CSQ | CSRS
Capacitive measurement type: Cp (parallel capacitance), Cs
(serial capacitance), D (dissipation factor), Q (quality factor), G
(conductance), Rp (parallel resistance), Rs (serial resistance)
LPD | LPQ | LPG | LPRP | LPRDc | LSD | LSQ | LSRS |
LSRDc
Inductive measurement type: Lp (parallel inductance), Ls (serial
inductance), D (dissipation factor), Q (quality factor), G (conduc-
tance), Rp (parallel resistance), Rs (serial resistance), RDc
(direct current resistance)
RX | RPB | RDC | MTD | NTD | ZTD | ZTR | GB | YTD | YTR
Resistance measurement type: R (resistance), X impedance, Rp
(parallel resistance), RDC (direct current resistance), B (suscep-
tance), M (mutual inductance), N (transformer ratio), Z (impe-
dance), G (conductance), Y (admittance), TD (phase angle
degree), TR (phase angle rad)
Example:
See Example "Selecting the measurement function and setting
the impedance range" on page 195.
Manual operation: See "<measurement pair>" on page 70
FUNCtion subsystem
