R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
181User Manual 1335.7352.02 ─ 02
Parameters:
<Coupling> DCLimit | ACLimit | GND
DCLimit
DC coupling
ACLimit
AC coupling
GND
Ground
*RST: DCL
CHANnel<m>:SCALe
<Scale>
Sets the vertical scale for the indicated channel.
Suffix:
<m>
.
Selects the input channel (1, 2).
Parameters:
<Scale> Scale value, given in Volts per division.
Range: 1e-3 to 10
*RST: 5e-3
CHANnel<m>:RANGe <Range>
Sets the voltage range across the 8 vertical divisions of the diagram. Use the com-
mand alternativly instead of CHANnel<m>:SCALe.
Suffix:
<m>
.
Selects the input channel (1, 2).
Parameters:
<Range> Voltage range value
Range: 8e-3 to 80
*RST: 40e-3
CHANnel<m>:POSition <Position>
Sets the vertical position of the indicated channel and its horizontal axis in the window.
Suffix:
<m>
.
Selects the input channel (1, 2).
Parameters:
<Position> Position value, given in divisions.
Range: -4 to 4
*RST: 0
Acquisition and Setup
