R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
206User Manual 1335.7352.02 ─ 02
Example:
TRIG:A:PATT:SOUR „1X“
CH1 = High, CH2 = Don‘t care (POD deactivated)
TRIG:A:PATT:SOUR „00101X1X1X“
POD: 0 = High, 1 = Low, ... , 7 = Don‘t care (CH1 / CH2 deacti-
vated)
TRIGger:A:PATTern:FUNCtion <Function>
Sets the logical combination of the trigger states of the channels.
Parameters:
<Function> AND | OR
AND
The required states of all channels must appear in the input sig-
nal at the same time.
OR
At least one of the channels must have the required state.
*RST: AND
TRIGger:A:PATTern:CONDition <ConditionString>
Sets the trigger point depending on the result of the logical combination of the channel
states.
Parameters:
<ConditionString> „TRUE“ | „FALSE“
*RST: „TRUE“
TRIGger:A:PATTern:MODE <PatternMode>
Sets the duration function of the pattern trigger.
Parameters:
<PatternMode> OFF | TIMeout | WIDTh
OFF
Pattern trigger without duration.
TIMeout
Defines how long at least the result of the state pattern condition
must be true or false.
WIDTh
Width duration and comparision of the logical combined chan-
nels. The range is defined using TRIGger:A:PATTern:
WIDTh:RANGe
*RST: OFF
Trigger
