Remote Commands Reference
R&S
®
RTC1000
207User Manual 1335.7352.02 ─ 02
TRIGger:A:PATTern:WIDTh[:WIDTh] <PatternWidth>
For the ranges WITHin and OUTSide (defined using TRIGger:A:PATTern:WIDTh:
RANGe), the <PatternWidth> defines the center of a range which is defined by the limits
±<Delta> (set with TRIGger:A:PATTern:WIDTh:DELTa).
For the ranges SHORter and LONGer, the pattern width defines the maximum and
minimum values, respectively.
Parameters:
<PatternWidth> Center value, maximum value or minimum value depending on
the defined range type.
Range: 1.600E-08 to 3.435974E+01
*RST: 3.9999999E-04
Default unit: s
TRIGger:A:PATTern:WIDTh:DELTa
<PatternDelta>
Defines a range around the pattern width value specified using TRIGger:A:
PATTern:WIDTh[:WIDTh].
Parameters:
<PatternDelta> ±Δt ("Variation")
Range: 8.00E-09 to maximum value, which depends on
the defined pulse width
*RST: 1.5000000E-04
TRIGger:A:PATTern:WIDTh:RANGe <PatternRange>
Defines a range around the width value specified using TRIGger:A:PATTern:
WIDTh[:WIDTh].
Parameters:
<PatternRange> WITHin | OUTSide | SHORter | LONGer
WITHin | OUTSide
Triggers on pulses inside or outside a range defined by time ±
delta. The time is specified with TRIGger:A:PATTern:
WIDTh[:WIDTh], the range around is defined with TRIGger:
A:PATTern:WIDTh:DELTa
SHORter | LONGer
Triggers on pulses shorter or longer than a time set with
TRIGger:A:PATTern:WIDTh[:WIDTh]
*RST: LONGer
Trigger
