CALCulate:QMATh:DATA:HEADer?
Returns information on the quick math waveform.
Table 13-2: Header data
Position Meaning Example
1 XStart in s -9.477E-008 = - 94,77 ns
2 XStop in s 9.477E-008 = 94,77 ns
3 Record length of the waveform in Samples 200000
4 Number of values per sample interval, usually 1. 1
Return values:
<DataHeader> Comma-separated value list.
Example: -9.477E-008,9.477E-008,200000,1
Usage: Query only
CALCulate:QMATh:DATA:XINCrement?
Returns the time difference between two adjacent samples of the indicated waveform.
The command is relevant for data conversion, if binary data format is defined (FORM
UINT,8|16|32).
Return values:
<Xincrement> Time in s
Usage: Query only
CALCulate:QMATh:DATA:XORigin?
Returns the time of the first sample of the indicated waveform. The command is rele-
vant for data conversion, if binary data format is defined (FORM UINT,8|16|32).
Return values:
<Xorigin> Time in s
Usage: Query only
CALCulate:QMATh:DATA:YINCrement?
Returns the voltage value per bit of the indicated waveform. The command is relevant
for data conversion, if binary data format is defined (FORM UINT,8|16|32).
Return values:
<Yincrement> Voltage in V
Usage: Query only
