Remote Commands Reference
R&S
®
RTC1000
253User Manual 1335.7352.02 ─ 02
Parameters:
<TriggerMode> CONTinuous | SINGle | EXTern
CONTinuous
The CONT function (continuous trigger) issues the pattern con-
tinuously.
SINGle
If the SING setting is activated, the pattern is issued manually.
EXTern
For the EXT (external trigger) setting the pattern is issued by an
edge at the external input of the oscilloscope (TRIG.EXT.).
*RST: CONT
PGENerator:PATTern:TRIGger:SINGle
Manual output of a pattern (single trigger).
Usage:
Event
PGENerator:PATTern:TRIGger:EXTern:SLOPe <Slope>
Defines the slope of the external arbitrary pattern trigger.
Parameters:
<Slope> POSitive | NEGative | EITHer
POSitive
Rising edge (rise).
NEGative
Falling edge (fall).
EITHer
Rising as well as the falling edge (both).
*RST: POS
PGENerator:PATTern:ARBitrary:DATA[:SET] <ArbitraryData>
Defines the arbitrary pattern.
Parameters:
<ArbitraryData> List of values
Example:
PGEN:PATT:ARB:DATA 0,1,1,1,2,0,3,1,4,0
PGENerator:PATTern:ARBitrary:DATA:APPend <AppendData>
Defines the arbitrary pattern.
Parameters:
<AppendData> List of Values
Pattern Generator
