R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
254User Manual 1335.7352.02 ─ 02
Example:
PGEN:PATT:ARB:DATA:APP 4
From index = n the oscilloscope appends a 4 in HEX to the pat-
tern.
Usage: Setting only
PGENerator:PATTern:ARBitrary:DATA:APPend:BOR <AppendData>
Parameters:
<AppendData> List of values
From index = n data will be integrated in existing pattern via OR
combination.
PGENerator:PATTern:ARBitrary:DATA:APPend:BAND <AppendData>
Selects the pattern generator function.
Parameters:
<AppendData> List of values
From index = n data will be integrated in existing pattern via
AND combination.
PGENerator:PATTern:ARBitrary:DATA:APPend:INDex <AppendIndex>
Defines the index of the arbitrary pattern.
Parameters:
<Function> Numeric value
Example:
PGEN:PATT:ARB:DATA:APP:IND 5
PGEN:PATT:ARB:DATA:APP 4
From index = n a pattern length of 6 will be defined with last high
bit 4.
PGENerator:PATTern:ARBitrary:DATA:LENGth <PatternLength>
Defines the arbitrary pattern length.
Parameters:
<PatternLength> Numeric value
Range: 1 to 2048
*RST: 1
PGENerator:PATTern:COUNter:FREQuency <Period>
Defines the frequency value of the pattern generator counter function. The user fre-
quency always refers to the switching of the pattern condition. This results in square
waveforms for individual pins.
Pattern Generator
