R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
255User Manual 1335.7352.02 ─ 02
Pin Frequency
S0 f/2
S1 f/4
S2 f/8
S3 f/16
Parameters:
<Period> Numeric value
Range: 2.380952425301E-02 to 2.500000000000E+07
*RST: 1.000000000000E+05
PGENerator:PATTern:COUNter:DIRection
<CountDirection>
Sets the pattern generator counter direction.
Parameters:
<CountDirection> UPWard | DOWNward
*RST: UPW
PGENerator:PATTern:SQUarewave:POLarity <Polarity>
Defines the polarity of the pattern generator square wave function.
Parameters:
<Polarity> NORMal | INVerted
*RST: NORM
PGENerator:PATTern:SQUarewave:DCYCle <DutyCycle>
Selects the pattern generator function.
Parameters:
<DutyCycle> Numeric value
Range: 1.00E+00 to 9.900E+01
*RST: 5.000E+01
Default unit: %
Example:
PGEN:PATT:SQU:DCYC 20
Sets the duty cycle of the square wave function to 20 %.
PGENerator:MANual:STATe<s> <State>
Suffix:
<s>
.
0...3
Selects the pins S0 to S3 manually.
Pattern Generator
