R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
265User Manual 1335.7352.02 ─ 02
BUS<b>:STATe <State>
Switches the protocol display on or off.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<State> ON | OFF
*RST: OFF
BUS<b>:TYPE
<Type>
Defines the bus or interface type for analysis. For most types, a special option to the
instrument is required.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<Type> PARallel | CPARallel | I2C | SPI | SSPI | UART | CAN | LIN
*RST: PARallel
BUS<b>:FORMat <Format>
Sets the decoding format for the display on the screen.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<Format> ASCii | HEXadecimal | BINary | DECimal
*RST: HEX
BUS<b>:DSIZe <DisplaySize>
Sets the height of the decoded bus signal on the sreen.
Suffix:
<b>
.
1..4
Selects the bus.
Parameters:
<DisplaySize> SMALl | MEDium | LARGe
*RST: MEDium
Protocol Analysis
