R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
266User Manual 1335.7352.02 ─ 02
BUS<b>:DSIGnals <BitsSignals>
Displays the individual bit lines above the decoded bus line.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<BitsSignals> ON | OFF
*RST: ON
BUS<b>:POSition
<Position>
Sets the vertical position of the decoded bus signal in divisions on the sreen.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<Position> Range: -4 to 4
*RST: 1
Default unit: div
BUS<b>:LABel <Label>
Defines an additional name label for the selected bus.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<Label> String value
The maximum name length is 8 characters, and only ASCII
characters provided on the on-screen keyboard can be used.
BUS<b>:LABel:STATe <State>
Displays or hides the bus label. The bus label is shown on the the right side of the dis-
play.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<State> ON | OFF
*RST: ON
Protocol Analysis
