R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
279User Manual 1335.7352.02 ─ 02
13.16.5
I
2
C Bus
●
I
2
C - Configuration.................................................................................................279
● Trigger...................................................................................................................280
● Decode..................................................................................................................283
13.16.5.1
I
2
C - Configuration
BUS<b>:I2C:CLOCk:SOURce.........................................................................................279
BUS<b>:I2C:DATA:SOURce...........................................................................................279
BUS<b>:I2C:AMODe......................................................................................................279
BUS<b>:I2C:CLOCk:SOURce <Source>
Sets the input channel to which the clock line is connected.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<Source> CH1 | CH2 | D0 .... D7
*RST: CH1
BUS<b>:I2C:DATA:SOURce <Source>
Sets the input channel to which the data line is connected.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<Source> CH1 | CH2 | D0 .... D7
*RST: CH1
BUS<b>:I2C:AMODe <BusConfig>
Defines if the R/W bit of a 7-bit address is considered separately or as part of the
address. The setting defines which address lengths are available with TRIGger:A:
I2C:MODE
Suffix:
<b>
.
1, 2
Selects the bus.
Protocol Analysis
