Remote Commands Reference
R&S
®
RTC1000
292User Manual 1335.7352.02 ─ 02
Parameters:
<Parity> ODD | EVEN | NONE
*RST: NONE
BUS<b>:UART:SBIT <StopBitNumber>
Sets the stop bits.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<StopBitNumber> B1 | B1_5 | B2
1; 1.5 or 2 stop bits are possible.
*RST: B1
BUS<b>:UART:BAUDrate
<Baudrate>
Sets the number of transmitted bits per second.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<Baudrate> Range: 6.0E+01 to 1.56E+07
*RST: 1.15200E+05
Default unit: Bit
BUS<b>:UART:BITime <BurstIdleTime>
Sets the minimal time between two data frames (packets), that is, between the last
stop bit and the start bit of the next frame.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<BurstIdleTime> Range: 9.54880E-05 to 2.6843137E-01
*RST: 1.1458333E-03
Default unit: s
13.16.6.2 Trigger
TRIGger:A:UART:MODE................................................................................................ 293
TRIGger:A:UART:PATTern............................................................................................. 293
TRIGger:A:UART:PLENgth............................................................................................. 293
TRIGger:A:UART:POFFset............................................................................................. 294
Protocol Analysis
