R&S
®
RTC1000
294User Manual 1335.7352.02 ─ 02
Parameters:
<PatternLength> Number of symbols
Range: 1 to 3
Increment: 1
*RST: 1
TRIGger:A:UART:POFFset <PatternByteOffset>
Sets the number of symbols before the first symbol of the pattern.
Parameters:
<PatternByteOffset> Number of ignored symbols
Range: 0 to 4095
Increment: 1
*RST: 0
13.16.6.3 Decode
BUS<b>:UART:FCOunt?................................................................................................ 294
BUS<b>:UART:FRAMe<n>:WCOunt?..............................................................................294
BUS<b>:UART:FRAMe<n>:WORD<o>:VALue?................................................................295
BUS<b>:UART:FRAMe<n>:WORD<o>:STARt?................................................................295
BUS<b>:UART:FRAMe<n>:WORD<o>:STOP?.................................................................295
BUS<b>:UART:FRAMe<n>:WORD<o>:STATe?............................................................... 295
BUS<b>:UART:FCOunt?
Returns the number of frames.
Suffix:
<b>
.
1, 2
Selects the bus.
Return values:
<FrameCount> Total number of decoded frames.
Usage: Query only
BUS<b>:UART:FRAMe<n>:WCOunt?
Returns the number of words of a frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<WordCount> Number of words (symbols, characters)
Usage: Query only
Protocol Analysis
