R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
311User Manual 1335.7352.02 ─ 02
TRIGger:A:LIN:IDENtifier <Identifier>
Specifies the identifier, only 6 character are allowed.
Parameters:
<Identifier> String containing binary pattern. Characters 0, 1, and X are
allowed. Enter the 6 bit identifier without parity bits, not the pro-
tected identifier.
Example:
TRIG:A:LIN:IDEN "100001"
TRIGger:A:LIN:DCONdition
<DataCondition>
Specifies the condition for the data.
Parameters:
<DataCondition> EQUal | NEQual | GTHan | LTHan
EQUal
Sets the condition for identifier to equal.
NEQual
Sets the condition for identifier to not equal.
GTHan
Sets the condition for identifier to greater than.
LTHan
Sets the condition for identifier to less than.
*RST: EQU
TRIGger:A:LIN:DATA <Data>
Specifies the data for LIN trigger. Depending of TRIGger:A:LIN:DLENgth setting
the number of characters is fixed, all bytes need to be complete.
Parameters:
<Data> String containing binary pattern with max. 64 bit. Characters 0,
1, and X are allowed. Make sure to enter complete bytes.
Example:
TRIG:A:LIN:DATA "10100101"
TRIGger:A:LIN:DLENgth <DataLength>
Defines the length of the data pattern - the number of bytes in the pattern.
Parameters:
<DataLength> Range: 1 to 8
Increment: 1
*RST: 1
Default unit: Byte
Protocol Analysis
