Status Reporting System
R&S
®
RTC1000
355User Manual 1335.7352.02 ─ 02
Bit No. Meaning
8
NOALigndata
This bit is set if no alignment data is available - the instrument is uncalibrated.
9
LIMit
This bit is set if a limit value is violated (see Chapter C.3.4.3, "STATus:QUEStionable:LIMit reg-
ister", on page 355).
10 and
11
Not used
12
MASK
This bit is set if a mask value is violated (see Chapter C.3.4.4, "STATus:QUEStionable:MASK
register", on page 356).
13 and
14
Not used
15 This bit is always 0.
C.3.4.1 STATus:QUEStionable:COVerload register
This register contains all information about overload of the channels. The bit is set if
the assigned channel is overloaded, or if an overload risk occured (overload warning).
Table C-5: Bits in the STATus:QUEStionable:COVerload register
Bit No. Meaning
0 Overload on CHANnel1
1 Overload on CHANnel2
C.3.4.2 STATus:QUEStionable:TEMPerature register
This register contains information about the instrument's temperature.
Table C-6: Bits in the STATus:QUEStionable:TEMPerature register
Bit No. Meaning
0
TEMP WARN
This bit is set if a temperature warning on channel 1 or 2 occured.
1
TEMP ERRor
This bit is set if a temperature error on channel 1or 2 occured.
C.3.4.3 STATus:QUEStionable:LIMit register
These registers contain information about the observance of the limits of measure-
ments. The LIMit bit is set if the limit of the assigned measurement is violated.
Contents of the Status Registers
