Rexroth EcoDrive Cs Drives Mains and Supply Voltage Connection 6-9
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Stopped
2003/07/03 13:10:04 5ms/div
(5ms/div)
NORM:200kS/s
CH1=100mV
DC 1:1
CH4=20V
DC 10:1
=Filter=
Smoothing : OFF
BW : FULL
=Offset=
CH1 : 0.004V
CH2 : 0.003V
CH3 : 0.000V
CH4 : 0.0V
=Record Length=
Main : 10K
Zoom : 10K
=Trigger=
Mode : NORMAL
Type : EDGE CH1
Delay : 0.0ns
Holdoff : MINIMUM
Fig. 6-10: I L1 (upper curve) and mains voltage or transformer output (lower
curve) when switching on (time basis: T = 5 ms/div)
I L1 when switching on mains
voltage
