8-36 Motors Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Absolute Encoder
Provided for absolute indirect position detection within 65536 motor
revolutions. Replaces separate absolute value encoders at the motor.
Note: The absolute axis position at this encoder variety still exists
because of the battery back-up also after power shut down.
If you disconnect the motor from the drive controller, you will
lose the absolute axis position after approx. 1 minute.
Power supply
Designation Value Note
main power supply
5 V ±5%
battery 3.6 V Battery allows:
• holding data (in multiturn operation)
• multiturn operation when power supply fails
See also chapter "Additional Components" → "Accessories"
→ "SUP-E03-DKC*CS-BATTRY"
Changing battery: see page 8-45
Fig. 8-48: Power supply
