5-20 Electrical Connections Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
line cross section
min. 1 mm
2
voltage stability of a single strand against
ground:
≥ 750 V
line routing: parallel where possible (twist)
max. inductance between 24 V source
and X5_3:
100 µH
(corresponds to approx. 2 x 75 m)
The drive controller assumes the control of the holding brake.
Line for Voltage Connection of
Brake
Controlling the Motor Holding
Brake
