Type 5002
(D629)
5.5 IP-FAX
5.5.1 WHAT IS IP-FAX?
For details: Core Technology Manual – Facsimile Processes – Faxing from a PC – Internet/LAN
Fax Boards – IP-FAX
5.5.2 T.38 PACKET FORMAT
TCP is selected by default for this machine, but you can change this to UDP with IPFAX SW 00 Bit
1.
UDP Related Switches
IP-Fax Switch 01
No. Function Comments
0-3
Select IP FAX Delay Level Raise the level by selecting a higher
setting if too many transmission errors
are occurring on the network.
If TCP/UDP is enabled on the network,
raise this setting on the T.30 machine.
Increasing the delay time allows the
recovery of more lost packets.
If only UDP is enabled, increase the
number of redundant packets.
Level 1~2: 3 Redundant packets
Level 3: 4 Redundant packets
Bit 3 Bit 2 Bit 1 Bit 0 Level
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
0 0 1 1 3
To Next Page
