Ricoh D129 - Page 287

Main SP Tables-4
D129/D130 5-28 SM
4625 Black Level Adj. Display
001
Latest: BE Color
[0 to 16383 / 0 / 1 digit]
Displays the black offset value (rough adjustment) for the even blue signal in the
SBU (color printing speed).
002
Latest: BO Color
[0 to 16383 / 0 / 1 digit]
Displays the black offset value (rough adjustment) for the odd blue signal in the
SBU (color printing speed).
 BE: Blue Even signal, BO: Blue Odd signal
4628
Analog Gain Adjust
Displays the gain value of the amplifiers on the controller for Red.
Only for the color scanner
001 Latest: R Color [0 to 7 / 0 / 1 digit]
4629
Analog Gain Adjust
Displays the gain value of the amplifiers on the controller for Green.
SP4629-003 and -004 are used only for the color scanner model.
001 Latest: G Color [0 to 7 / 0 / 1 digit]
4630
Analog Gain Adjust
Displays the gain value of the amplifiers on the controller for Blue.
001 Latest: B Color [0 to 7 / 0 / 1 digit]
