System SP Table-1
D129/D130 3-8 SM Appendix
1109*
Fusing Nip Band Check
Checks the fusing nip band.
001 Execution
002
Idling Rotation Time [0 to 120 / 60 / 1 sec]
Specifies the fusing rotation time before executing SP1109-001.
003
Pre-Idling Time [5 to 30 / 10 / 1 sec]
Specifies the time that the paper stops in the fusing unit for measuring the
nip.
1159
Fusing Jam Detection
SC Code Display
[0 to 1 / 0 / 1] 0:OFF, 1:ON
This SP setting determines whether SC559 is issued after three paper late
jams occur in the fusing unit. After this SP code is turned on, a counter
monitors the number of paper late jams that occur in the fusing unit. After
the 3rd occurrence of a fusing jam, SC559 is issued and the machine
cannot be used until the service technician releases the error.
Switching the machine off/on does not reset this jam counter. The
counter is reset after the cause of the jam has been removed and a
sheet of paper successfully passes the fusing exit sensor.
