Ricoh D158 - Page 460

Main SP Tables-1
D158/D159/D160/D161/D170 3-2 SM Appendix
1002
[Side-to-Side Registration] (D158/D159)
[S-to-S Regist] (D160/D161/D170)
Adjusts the printing side-to-side registration from each paper feed station,
using the Trimming Area Pattern (SP 5902, No.10). Adjustments are
supported for all 4 possible feed tra
ys (including optional trays). The SP 1002
1 setting is applied to all trays, not just the 1st tray. Settings for trays 2 to 4 are
offsets relative to the SP 1002 1 setting. For duplex copies, the value for the
front side is determined by SP 1002 1 to 4, and the value for the rear side is
determined by SP 1002 6.
001 By-pass *ENG
[-4.0 to 4.0 / 0.0 / 0.1 mm / step]
002 Tray Main1 *ENG
[-4.0 to 4.0 / 0.0 / 0.1 mm / step]
003 Tray Main2 *ENG
[-4.0 to 4.0 / 0.0 / 0.1 mm / step]
004 Tray Bank1 *ENG
[-4.0 to 4.0 / 0.0 / 0.1 mm / step]
005 Tray Bank2 *ENG
[-4.0 to 4.0 / 0.0 / 0.1 mm / step]
006 Duplex *ENG
[-4.0 to 4.0 / 0.0 / 0.1 mm / step]
1003
[Paper Buckle] Paper Buckle Adjustment
(Tray Location, Paper Type)
Adjusts the amount of paper buckle on the registration roller.
002 Tray1: Plain *ENG
[-9 to 5 / 0 / 1 mm / step]
003 Tray1: Middle Thick *ENG
[-9 to 5 / 0 / 1 mm / step]
004 Tray1: Thick *ENG
[-9 to 5 / 0 / 1 mm / step]
007 Tray2/3/4: Plain *ENG
[-9 to 5 / 0 / 1 mm / step]
008
Tray2/3/4: Plain: Middle
Thick
*ENG
[-9 to 5 / 0 / 1 mm / step]
009 Tray2/3/4: Plain: Thick *ENG
[-9 to 5 / 0 / 1 mm / step]
012 By-pass: Plain *ENG
[-9 to 5 / 0 / 1 mm / step]
013 By-pass: Middle Thick *ENG
[-9 to 5 / 0 / 1 mm / step]
