Main SP Tables-4
SM Appendix 3-77 D158/D159/D160/D161/D170
Appendix:
Service
Program
Mode Tables
4954
[Read/Restore:Std] (D158/D159 )
Reads or restores the standard chart.
005 Chroma Rank *ENG
Restores the standard chromaticity rank.
[0 to 255 / 0 / 1 / step]
4991
[IPU Image Pass Selection] (D158/D159 )
-
001 RGB Frame Memory ENG
[0 to 19 / 2 / 1 / step ]
002 Filter test output ENG
[0 to 28 / 24 / 1 / step ]
003 Filter FM output ENG
[0 to 15 / 1 / 1 / step ]
004 Filter CPR output ENG
[0 to 15 / 0 / 1 / step ]
4993
[High Light Correction] (D158/D159 )
-
001 Sensitivity Selection *ENG
Selects the Highlight correction level.
[0 to 9 / 4 / 1 / step]
0: weakest sensitivity
9: strongest sensitivity
002 Range Selection *ENG
Selects the range level of Highlight
correction.
[0 to 9 / 4 / 1 / step]
0: weakest skew correction,
9: strongest skew correction
