Main SP Tables-5
D158/D159/D160/D161/D170 3-182 SM Appendix
5902
[Test Pattern] (D160/D161/D170)
Do not operate the machine until the test pattern is printed out
completely. Otherwise, an SC occurs.
1. Enter the SP mode and select SP5-902-001.
2. Enter the number for the test pattern that you want to print and press [#].
3. When you are prompted to confirm your selection, touch "Yes" to select
the test pattern for printing.
4. Touch "Copy Window" to open the copy window, then select the settings
for the test print (paper size etc.).
5. Press the "Start" key to start the test print.
6. After checking the test pattern, touch "SP Mode" on the LCD to return to
the SP mode display.
7. Reset SP5-902-001 to “0”.
8. Touch "Exit" twice to exit SP mode.
001 Test Pattern *ENG
[0 to 255 / 0 / 1 / step]
No. Pattern No. Pattern
0 None 11 Independent Pattern (1dot)
1 Vertical Line (1dot) 12 Independent Pattern (2dot)
2 Vertical Line (2dot) 13 Independent Pattern (4dot)
3 Horizontal Line (1dot) 14 Trimming Area
4 Horizontal Line (2dot) 15 Black Band (Horizontal)
5 Grid Vertical Line 16 Black Band (Vertical)
6 Grid Horizontal Line 17 Checker Flag Pattern
7 Grid Pattern Small 18 Grayscale (Vertical)
8 Grid Pattern Large 19 Grayscale (Horizontal)
9 Argyle Pattern Small 20 Full Dot Pattern
10 Argyle Pattern Large 21 All White Pattern
