Ricoh MP 2014 Series - Loading Paper

Print Area
The diagram below shows the area of the paper that the machine can print on.
Paper
DJC061
1
2
5
4
3
5
1. Print area
2. Feed direction
3. Approx. 3 mm (0.11 inches)
4. Approx. 5 mm (0.19 inches)
5. Approx. 2 mm (0.07 inches)
Envelope
1
2
3
3
3
DJC063
3
1. Print area
2. Feed direction
3. Approximately 10 mm (0.39 inches)
2. Loading Paper
58
