8.7.8 Runt Trigger

The runt trigger sets the oscilloscope to trigger pulses that cross one trigger level but

not another, as shown in the figure below.

Lower Limit of the

Trigger Level

Upper Limit of the

Trigger Level

Negative Runt Pulse

Positive Runt Pulse

Figure 8.15 Runt Trigger

Trigger Type

Click or tap the drop-down button of Type to select "Runt".

Figure 8.16 Runt Trigger Setting Menu

After a trigger type is selected, the current trigger setting information (including

trigger type, trigger source, and trigger level) is displayed in the trigger information

label at the top of the screen, as shown in the figure below. The information will

change based on the trigger settings.
