Edge Type=

Edge Num=2

P<Idle Time<M

Figure 8.22 Nth Edge Trigger

Trigger Type

Click or tap the drop-down button of Type to select "Nth Edge".

Figure 8.23 Nth Edge Trigger Setting Menu

After a trigger type is selected, the current trigger setting information (including

trigger type, trigger source, and trigger level) is displayed in the trigger information

label at the top of the screen, as shown in the figure below. The information will

change based on the trigger settings.

Triggering the Oscilloscope

HDO1000 User Guide
