13.2 To Select the Source
Click or tap the drop-down button of Source to select the desired source. The
available output channels include CH1-CH4.
TIP
When a disabled channel is selected as the source, it will be automatically turned on.
13.3 To Create a Mask
In the Pass/Fail menu, you can self-define the mask of the pass/fail test. The mask can
be imported or exported.
To Create a Mask
Click or tap X Mask and Y Mask respectively to set the horizontal tolerance range
and vertical tolerance range with the pop-up numeric keypad. You can also use the
icons at the right side of the input fields or use the corresponding multipurpose knob
to set the values. Then click or tap
Create to apply the currently created mask (the
region not covered by blue within the screen).
To Load a Mask
When the pass/fail test function is enabled, you can load the test mask files from the
internal memory or external USB storage device (when detected) and apply them to
the current pass/fail test function.
Click or tap
Load to enter the file loading interface. Click or tap the input field of File
Path to load the specified test mask files (in *.pf format) and apply them to the
current pass/fail test function. For details, refer to descriptions in
Disk Management
section in
Store and Load
.
To Save the Mask
When the pass/fail test function is enabled, you can save the current test mask range
to the internal memory or external USB storage device (when detected) in "*.pf"
format.
Click or tap
Save to enter the file saving interface. Click or tap the input field of File
Name and File Path to input the filename and select the desired file path to save the
test mask file to the internal or external memory. For details, refer to descriptions in
Disk Management
section in
Store and Load
.
13.4 To Set the Output Form of the Test Results
In Option, you can set what the oscilloscope will execute when test results are
detected according to your needs.
Pass/Fail Test
HDO1000 User Guide
168
