10.1.2 Count Values

The default values for threshold upper limit and threshold low limit are 90% and 10%,

respectively.

Positive Pulse Count

It is specified as the number of positive pulses that rise from under the threshold

lower limit to above the threshold upper limit.

Positive Pulse Count = n

1 n2

Threshold

Upper Limit

Threshold

Lower Limit

Negative Pulse Count

It is specified as the number of negative pulses that fall from above the threshold

upper limit to below the threshold lower limit.

1 n2

Negative Pulse Count = n

Threshold

Upper Limit

Threshold

Lower Limit

Rising Edge Count

It is specified as the number of rising edges that rise from under the threshold lower

limit to above the threshold upper limit.

Measurements

HDO1000 User Guide

136
