8.8 Trigger Output Connector

The rear-panel trigger output connector ([AUX OUT]) of this series can output trigger

signals determined by the current setting (hardware trigger).

Click or tap > Utility. Click or tap Setup, and then select "TrigOut" in Aux Out. A

signal which reflects the current oscilloscope capture rate can be output from [AUX

OUT] connector each time a trigger is generated by the oscilloscope. If this signal is

connected to a waveform display device to measure the frequency, the measurement

result is the same as the current capture rate.

If "PassFail" is selected in

Aux Out, the instrument can output a pulse from the [AUX

OUT] connector when a pass/failed event is detected during the pass/fail test.
