Statistics Results

Click or tap the Statistic on/off switch to turn on/off displaying all statistical items.

When enabled, all the statistical results will be displayed in the "Counter" label in the

"Result" bar.

11.2.2 Reset Statistics

Click or tap the "Counter" label in the "Result" bar at the right section of the screen

and a window is displayed. Click or tap Reset Stat. in the window to reset the

statistics.

11.2.3 Remove the Measurement

Click or tap the "Counter" label in the "Result" bar and a window is displayed. Click or

tap Remove to clear the measurement results. The "Counter" label disappears from

the "Result" bar accordingly. You can also click or tap Remove in the counter setting

menu to disable the function.

Digital Voltmeter (DVM) and Frequency Counter

HDO1000 User Guide

162
