Figure 19.4 Load Setting Menu

Load Setup

Click or tap the drop-down button of Choose to select "Load Setup". Then, click or

tap File Path to load the setups from the internal memory or the external USB disk.

The default file type is "*.stp", and no other options are available. Select the file to be

loaded from the memory. Click or tap

Load to load the selected file.

19.4 System Upgrade

This instrument supports local upgrade and online upgrade.

Local upgrade

1. In the storage setting menu, click or tap Upgrade to enter the local upgrade

setting menu.

Store and Load

HDO1000 User Guide

220
