To Next Page

To Previous Page

SCL

SDA

Figure 14.8 I2C Serial Bus

In the Decode menu, click or tap the drop-down button of Bus Type to select I2C,

then configure the parameters for I2C decoding.

Figure 14.9 I2C Decoding Menu

Bus Status

Click or tap the Bus Status on/off switch to enable or disable the bus decoding.

Quickly apply trigger settings to decoding

Copy trig indicates applying the trigger settings to the specified decoding setting.

Click or tap

Copy Trig to apply the trigger settings to the specified decoding setting.

14.3.1 Source Setting

Set the clock channel source and the threshold

• Click or tap the drop-down button of CLK to select the desired source of the

clock channel (CH1-CH4).

• Click or tap the input field of SCL Thre, and then use the pop-up numeric

keypad to set the threshold of the clock channel.

Protocol Decoding

HDO1000 User Guide

181
