Rigol HDO1000 Series User Manual

Figure 8.29 Hex Format Setting
• A&D: the oscilloscope searches for the specified address and data at the same
time, then triggers when both the address and data meet the conditions. After
this condition is selected, you need to set the sub-menu items such as
Direction,
Bytes, AddrBits, Address, and Data. For the setting methods, refer to
descriptions in "Address" and "Data" conditions.
Trigger Mode
In
Sweep, select Auto, Normal, or Single as the trigger mode. For details, refer to
Trigger Mode .
Trigger Parameter Setting
You can refer to Noise Rejection to set the noise rejection under this trigger type.
Level Selection and Setting
After the trigger condition setting is completed, you need to adjust the trigger level
to correctly trigger the signal and obtain a stable waveform.
• Level A
Click or tap the input field of
Level A to input the level of SCL with the pop-up
numeric keypad. You can also use the corresponding multipurpose knob or
trigger level knob to set the value. For details, refer to descriptions in
Trigger
Level . The current trigger level is displayed in the trigger information label at the
top of the screen.
Triggering the Oscilloscope
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
HDO1000 User Guide
103
