Rigol HDO1000 Series User Manual

When you modify the threshold of the clock channel, a dotted line displaying the
current threshold level is displayed on the screen. It disappears in about 2 s after
you stop modifying the threshold.
Set the signal
• Click or tap the drop-down button of Baud Rate to select the baud rate. The
available baud rates include 2.4 kbps, 4.8 kbps, 9.6 kbps, 19.2 kbps, and etc.
• In Parity bit, click or tap "With" or "Without" to select whether the data
contain the parity bit.
• In Version, select the protocol version that matches the LIN bus signal. The
available versions include "1.X", "2.X", and "Both".
14.5.2 Display-related Settings
In Decode menu, set the following display-related parameters.
Set the Display Format
Click or tap the drop-down button of Format to select the display format of the bus
data. The available options include "Hex", "Dec", "Bin", and "ASCII".
Set the Label Display
Click or tap the Label on/off switch to enable or disable the label display of the
decoding bus. When enabled, the bus label will be displayed at the upper-left side of
the bus (when the bus display is enabled). The label shows the current bus type.
14.5.3 Event Table
Open or Close the Event Table
Click or tap the Event Table on/off switch to enable or disable the display of the
event table. When enabled, the event table is displayed as shown in the figure below.
You can also click or tap the icon at the upper-right corner of the table to close
the event table.
Protocol Decoding
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
HDO1000 User Guide
189
