reference waveform to the internal memory or external USB storage device. Then
click or tap Save to complete the save operation. For details about the disk
management operation, refer to the Disk Management section in Store and
Load .
TIP
Only when the reference waveform is saved, can this export function be valid.
This series oscilloscope only supports the flash memory USB storage device of FAT32 format.
For the ".bin" format file, refer to
Binary Data Format (.bin) .
To Import from Internal or External Memory
You can import the stored reference waveform file from the internal memory or
external USB storage device to the internal instrument and display the file on the
screen.
Click or tap
Import to enter the reference waveform file loading interface.
• Set the Format
In the file loading interface, click or tap the drop-down button of Format to
select ".ref" as the loading format.
• Set the Load Path
Click or tap the input field of File Path, then the disk management interface is
displayed.
Through the disk management menu, you can load the current reference
waveform to the waveform view of the oscilloscope. Then click or tap
Load to
complete the load operation. For details about the disk management operation,
refer to the
Disk Management section in Store and Load .
Reference Waveform
HDO1000 User Guide
166
