Set the Event Table Format

In the Decode menu, click or tap the drop-down button of Format to select the

display format of "Data" in the event table. The available options include "Hex",

"Dec", "Bin", or "ASCII".

Interpret the Decoded CAN Data

• Frame ID: expressed in Hex, identified as "ID:".

• DLC (Data Length Code): expressed in Hex, identified as "DLC:".

• Data: Its display format is the same as that of the bus data (Hex, Dec, Bin, or

ASCII), identified as "Data:".

• CRC (Cyclic Redundancy Check): expressed in Hex, identified as "CRC:".

• ACK (Acknowledgement): identified as "ACK". When errors (ACK is detected to

be 1) occur, displayed as a red patch.

• R (remote frame): identified as "R:".

• Stuff (Bit filling error): identified as "Stuff".
