Parameter Factory Settings

Math Operation

Invert OFF

Expand GND

Display Label OFF

Grid FULL

A+B

Operation OFF

SourceA CH1

SourceB CH1

Scale 500 mV

Offset 0 V

A-B

Operation OFF

SourceA CH1

SourceB CH1

Scale 500 mV

Offset 0 V

A×B

Operation OFF

SourceA CH1

SourceB CH1

Scale 500 mU

Offset 0 U

A÷B

Operation OFF

SourceA CH1

SourceB CH1

Scale 500 mU

Offset 0 U

FFT

Operation OFF

Source CH1

X Span-Center

Unit dBm/dBV

Center Frequency 5 MHz

Frequency Span 10 MHz

Vertical Scale 20 dBV

Offset 0 dBV

Window Function Hanning

Color Grade OFF

Peak Search OFF

Store and Load
