After setup, click or tap the key at the upper-right corner of the front panel to
capture the current screen and save the image with the specified format. The location
where the file is saved depends on the File Path setting in Storage menu. For details,
please refer to
To Save a File
.
Save Wave
• Click or tap Save Wave, then Operation is set to "Save Wave".
• Select "Memory" or "Screen" under Data Source as the source of the saved
waveform.
• Available options under Format include "*.bin" and "*.csv".
After setup, click or tap the
key at the upper-right corner of the front panel to
save the waveform based on the settings. The location where the file is saved
depends on the
File Path setting in Storage menu. For details, please refer to
To Save
a File
.
Save Setup
Click or tap
Save Setup, then Operation is set to "Save Setup".
After setup, click or tap the key at the upper-right corner of the front panel to
save the setup file suffixed with "*.stp". The location where the file is saved depends
on the
File Path setting in Storage menu. For details, please refer to
To Save a File
.
All Measurement
• Click or tap All Measure, then Operation is set to "All Measure".
• In All Measure item, click or tap the drop-down button to select the channel
(CH1-CH4) to measure.
After setup, click or tap the
key at the upper-right corner of the front panel to
perform the measurement on the specified channel.
Reset Statistics
• Click or tap
Stat Reset, then Operation is set to "Stat Reset".
• Click or tap "Measure" or "Pass/Fail" under Stat Reset to reset all statistics of
the "Measure" or "Pass/Fail" fucntion.
After setup, click or tap the key at the upper-right corner of the front panel.
This resets all statistics of the specified function in the
Result sidebar at the right side
of the screen and begins recording statistical data again.
System Utility Function Setting
HDO1000 User Guide
242
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
