• When you select "Rising" for the edge type, ">" for trigger condition, the

oscilloscope triggers when the positive slope time of the input signal is greater

than the specified time.

• When you select "Rising" for the edge type, "<" for trigger condition, the

oscilloscope triggers when the positive slope time of the input signal is smaller

than the specified time.

• When you select "Rising" for the edge type, "< >" for trigger condition, the

oscilloscope triggers when the positive slope time of the input signal is greater

than the specified lower limit time and smaller than the specified upper limit

time.

• When you select "Falling" for the edge type, ">" for trigger condition, the

oscilloscope triggers when the negative slope time of the input signal is greater

than the specified time.

• When you select "Falling" for the edge type, "<" for trigger condition, the

oscilloscope triggers when the negative slope time of the input signal is smaller

than the specified time.

• When you select "Falling" for the edge type, "< >" for trigger condition, the

oscilloscope triggers when the negative slope time of the input signal is greater

than the specified lower limit time and smaller than the specified upper limit

time.

Slope Time Setting

• In the

When item, when ">" or "<" is set to trigger conditions, click or tap the

input field of Lower or Upper to set the lower limit value or the upper limit value

with the pop-up numeric keypad. You can also use the corresponding knob to

set the value. The slope time available is from 100 ps to 10 s.

• In the

When item, when "< >" is set to trigger conditions, click or tap the input

field of Upper and Lower respectively to set the lower limit value and the upper

limit value with the pop-up numeric keypad. You can also use the corresponding

knob to set the values. The lower slope time limit must be smaller than the

upper slope time limit.

Trigger Mode

Sweep, select Auto, Normal, or Single as the trigger mode. For details, refer to

Trigger Mode

Trigger Parameter Setting

You can refer to

Trigger Holdoff

and

Noise Rejection

to set the trigger holdoff and

noise rejection under this trigger type.
